  • JSM0129
JMP Marine Yanmar Minor Service Kit
  • JSM0129 - Minor Service Kit
Exploded View Parts Diagram

#JSM0129 JMP Marine Yanmar Engine Cooling Seawater Pump Minor Service Kit (Services JPR-YM06LPA, JPR-YM06LPB, Yanmar 119773-42502, 119773-42652, Johnson 10-24493-02, 10-24493-01)

USD $162.75 USD $120.89
(You save USD $41.86)
SKU:
JSM0129
Condition:
New
Weight:
3.00 LBS
Availability:
Usually ships within 24 hrs on business days from Miami FL USA
Current Stock:
PLEASE CONTACT US TO PLACE ORDER
Quantity:

Out of Stock

Product Description

#JSM0129 JMP Marine Minor Service Kit
Minor Service Kit for JMP Marine Yanmar Engine Cooling Raw Water / Seawater Pump(s): JPR-YM06LPA, JPR-YM06LPB, Yanmar 119773-42502, 119773-42652, Johnson 10-24493-02, 10-24493-01

PLEASE NOTE:
Minor Kit #JSM0129 can be used to service both JMP Marine & OEM / Genuine engine cooling raw water pumps
. JMP Marine uses the highest grade of materials in manufacturing all their parts & components which ensures the longest lasting performance product for the customer.

Minor
Service Kit #JSM0129 Includes:

7136-01 (FLEXIBLE IMPELLER) - QTY:1
CAMSET0042 (CAM SET) - QTY:1
ORG0061 (END COVER O-RING) - QTY:1
COV0050 (END COVER) - QTY:1
BOL0163 (END COVER SCREWS) - QTY:4
RET0013 (RETAINER) - QTY:1

JSM0129 Approx Total Lbs: 1.25 LBS / 0.57 kg

Service JMP Marine Yanmar Replacement Engine Cooling Pump(s) & OEM / Genuine . . .

JMP Marine Engine Cooling Pump: #JPR-YM06LPA
#JPR-YM06LPA Replaces Yanmar Pump P/N:
119773-42502

#JPR-YM06LPA Replaces Johnson P/N: 10-24493-02
#JPR-YM06LPA good for 6LP Series Engine Models:
6LP(A)-DTE(P), 6LP(A)-STE(P), 6LPA-STP2

JMP Marine Engine Cooling Pump: #JPR-YM06LPB
#JPR-YM06LPB Replaces Yanmar Pump P/N:
119773-42652 (replaces 119773-42650)

#JPR-YM06LPB Replaces Johnson P/N: 10-24493-01
#JPR-YM06LPB good for 6LP Series Engine Models:
6LP(A)-DTE(P), 6LP(A)-STE(P), 6LPA-STP2, 6LP(A)-DTZE(P), 6LP(A)-STZE(P), 6LPA-STZP2(3)

Picture of Pump listed Above:


JMP MARINE . . ."THE ONLY ONE"

Please note that shipping cost calculations are based on packaged weight which can be higher than the actual product weight.

SHIPPING COST SAVINGS - BULK ORDERS:
Possible discounts on total shipping costs for multiple unit orders; please contact sales department at sales@bigblueoceanmarine.com or by phone at 1 (250) 713-1018 for bulk order shipping quotes. Bulk orders are usually based on an order of 3 units or more.

Warranty Information

1 Year Manufactures Warranty.
*Warranty is void if not installed by licensed technician and/or approved repair facility.
