Product Description
#JSK0133 JMP Marine Major Service Kit
Major Service Kit for JMP Marine Engine Cooling Raw Water / Seawater Pump #JPR-S7633 & #JPR-S7635 (Replacement engine cooling pump for John Deere)
PLEASE NOTE:
Major Kit #JSK0133 can be used Only for pump JPR-S7633 & JPR-S7635; Cannot be used in Genuine Pumps other than JMP Marine Pumps.
WHY: Internal changes made to pump parts for better quality and performance.
Major Service Kit #JSK0133 Includes (All Internal Parts):
BER0039 (BEARING) - QTY:2
BOL0006 (HEX BOLT) - QTY:3
BOL0036 (SPRING WASHER) - QTY:3
BOL0037 (SPRING WASHER) - QTY:4
BOL0059 (HEX BOLT) - QTY:4
CAMSET0031 (CAM SET) - QTY:1
BOL0103 (SPRING WASHER) - QTY:1
BOL0193 (HEX NUT) - QTY:1
COV0036 (END COVER) - QTY:1
7608-01 (FLEXIBLE IMPELLER) - QTY:1
ORG0030 (O-RING, END COVER) - QTY:1
KEY0045 (KEY) - QTY:1
MCSSET0014 (MECHANICAL SEAL SET) - QTY:1
RET0055 (RETAINER) - QTY:1
SHA0145 (SHAFT) - QTY:1
SLI0006 (SLINGER) - QTY:1
SNP000301 (SNAP RING) - QTY:1
SPC0015 (SPACER) - QTY:1
SPC0034 (SPACER) - QTY:1
WER0019 (WEAR PLATE) - QTY:1
For JMP Marine Engine Cooling Raw Water / Seawater Pump(s) . . .
JMP Marine Engine Cooling Pump: #JPR-S7633
#JPR-S7633 Replaces John Deere Pump p/n(s): RE515657, DZ114697 (old RE517226, RE540399), DZ114700
#JPR-S7633 Replaces Sherwood Pump p/n(s): P1733X, P1733F-01
#JPR-S7633 good for Engine Models: 6068SFM50
JMP Marine Engine Cooling Pump: #JPR-S7635
#JPR-S7635 Replaces John Deere Pump p/n(s): RE538663
#JPR-S7635 Replaces Sherwood Pump p/n(s): P1735X, P1735-02
#JPR-S7635 good for Engine Models: 6068 Series
JMP MARINE . . ."THE ONLY ONE"
