Product Description
#JSK0001 JMP Marine Major Service Kit
Major Service Parts Repair Kit for JMP Marine General Multi-purpose Fluid Pump JPR-25UP.
PLEASE NOTE:
Major Kit #JSK0001 CAN ONLY be used to service JMP Marine Pump JPR-25UP. JMP Marine uses the highest grade of materials in manufacturing all their parts & components which ensures a longer lasting performance product.
Major Service Kit #JSK0001 Includes:
BER0002 (BEARING) - QTY:2
BOL0034 (FLAT WASHER) - QTY:1
BOL0037 (SPRING WASHER) - QTY:1
BOL0059 (HEX BOLT) - QTY:1
BOL0080 (HEX SCREW, END COVER) - QTY:7
CAMSET0003 (CAM SET) - QTY:1
COV0003 (END COVER) - QTY:1
7400-01K (FLEX IMPELLER) - QTY:1
KEY0002 (KEY) -QTY:1
MCSSET0008 (MECHANICAL SEAL SET) - QTY:1
ORG0013 (O-RING, END COVER) - QTY:1
RET0030 (OIL SEAL, RETAINER) - QTY:1
SHA0001 (SHAFT) - QTY:1
SLI0001 (SLINGER) - QTY:1
SNP0002 (SNAP-RING) - QTY:1
SNP0006 (SNAP-RING) - QTY:1
SNP0009 (SNAP-RING) - QTY:1
SPC0002 (SPACER) - QTY:1
Services JMP Marine General Multi-Purpose Fluid Pump . . .
JMP Marine General Multi-Purpose Fluid Pump: #JPR-25UP
JMP MARINE . . ."THE ONLY ONE"
