Product Description
#JPR-CP25UH JMP Marine CRANK MOUNTED Replacement Raw Water Engine Cooling Pump
Note: CRANK MOUNTED
*Make sure to review all product images and diagrams along with cross-reference information to confirm that this is the pump you need. If any questions please contact us by email or phone.
Includes:
- JMP Marine Replacement Engine Cooling Raw Water Pump #JPR-CP25UH
QTY: 1
Replacement For:
- Alaska Diesel, Crusader, Indmar, Jabsco, Johnson, Marine Power, Northern Lights, Pleasurecraft PCM, Sherwood, Sierra, Seamaxx, Volvo Penta
Product Information:
| SPECIFICATION | JPR-CP25UH |
| Uses JMP Marine Impeller p/n | 7136-01K |
| Pump Weight (approx) | 4.85 LBS (2.20 KG) |
| Pump Type | Crank Mounted Raw Water Pump |
| Port Size (mm/inches) | 32mm / 1.25" |
| Pump Size (mm/inches) | Length (124mm/4.88"), Width (114mm/4.49"), Height (117mm/4.61") |
| Replaces Alaska Diesel pump p/n | L6414A |
| Replaces Crusader, Pleasurecraft PCM, Seamaxx p/n(s) | RA057023, RA057024, RA057026 |
| Replaces Indmar p/n(s) | 685001, 685001-1, 685001-3, S685001 |
| Replaces Jabsco p/n | 50410-1201 |
| Replaces Johnson p/n(s) | F6B-9, 10-24232-1, 10-24930-01, 10-24805-01, 10-24076-2, 10-24228-1, 10-24915-1 |
| Replaces Marine Power p/n | 524520Z |
| Replaces Northern Lights p/n | 25-11030 |
| Replaces Sherwood p/n | P105 |
| Replaces Sierra p/n | 18-3587 |
| Replaces Volvo Penta p/n(s) | 3860703, 841640, 856513, 857451 |
| Used on Engine Model(s) | Crusader, Indmar, Marine Power, Pleasurecraft PCM, Volvo Penta & More |
| Compatible to OEM | YES |
| Major Service Kit (All Internal Parts) | JSK0148 (sold separately) |
| Minor Service Kit | JSM0148 (sold separately) |
Features:
- Plug & Play Replacement
- Heavy Duty Marine Grade Casting
- Marine Grade Shaft (3X Series Non-Magnetic)
- High Performance Flexible Impeller
- Crank Mounted
JMP MARINE . . ."THE ONLY ONE"
Please note that shipping cost calculations are based on packaged weight which can be higher than the actual product weight.
SHIPPING COST SAVINGS - BULK ORDERS:
Possible discounts on total shipping costs for multiple unit orders; please contact sales department at sales@bigblueoceanmarine.com or by phone at 1 (250) 713-1018 for bulk order shipping quotes. Bulk orders are usually based on an order of 3 units or more.
