Product Description
#JSM0143 JMP Marine Major Service Kit
Minor Service Parts Repair Kit for JMP Marine Caterpillar (CAT) Engine Cooling Raw Water / Seawater Pump JPR-CT0440, OEM Caterpillar Pump 4255412, 425-5412, Jabsco 29630-1201
PLEASE NOTE:
Minor Kit #JSM0143 can be used to service both JMP Marine & OEM / Genuine engine cooling raw water pumps (See note regarding mechanical seal set when servicing OEM pumps). JMP Marine uses the highest grade of materials in manufacturing all their parts & components which ensures the longest lasting performance product for the customer.
Minor Service Kit #JSM0143 Includes:
CAMSET0039 (CAM SET) - QTY:1
BOL0080 (END COVER SCREWS) - QTY:4
7400-01 (FLEXIBLE IMPELLER) - QTY:1
MCSSET0008 (MECHANICAL SEAL SET) - QTY:1
Note: MCSSET0008 can only be used to service JMP Marine pump JPR-CT0440. If using kit JSK0143 or JSM0143 to service OEM pump you MUST use original CAT mechanical seal p/n 4204328 in place of MCSSET0008. Why? JMP Marine Seal is thicker vs OEM Seal.
COV0047 (END COVER PLATE) - QTY:1
ORG0067 (O-RING, END COVER) - QTY:1
ORG0044 (O-RING, SLINGER) - QTY:1
ORG0057 (O-RING, MOUNTING) - QTY:1
SNP0006 (SNAP RING, SMALL) - QTY:1
SPC0019 (SPACER) - QTY: 1
WER0029 (WEAR PLATE) - QTY:1
JSM0143 Approx Total Lbs: 2.00 LBS / 1.00 kg
Services JMP Marine Caterpillar Replacement Engine Cooling Raw Water Pump & OEM / Genuine . . .
JMP Marine Engine Cooling Raw Water Pump: #JPR-CT0440
#JPR-CT0440 Replaces Caterpillar Pump P/N: 4255412, 425-5412
#JPR-CT0440 Replaces Jabsco Pump p/n: 29630-1201
#JPR-CT0440 Replaces Jabsco Pump P/N: 29630-1101 (see Note)
Note: You must confirm that your pump drive gear setup has same number of teeth being 33 which would then match with JPR-CT0440
#JPR-CT0440 good for Engine Models: C4.4
JMP MARINE . . ."THE ONLY ONE"
