Product Description
#JSK0124 JMP Marine Major Service Kit
Major Service Kit for JMP Marine Caterpillar (CAT) Engine Cooling Raw Water / Seawater Pump(s): JPR-CT3412, Caterpillar 7C3613, 3N7790, OR7720
PLEASE NOTE:
Major Kit #JSK0124 can be used to service both JMP Marine & OEM / Genuine engine cooling raw water pumps. JMP Marine uses the highest grade of materials in manufacturing all their parts & components which ensures the longest lasting performance product for the customer.
Major Service Kit #JSK0124 Includes (All Internal Parts):
BER0037 (BEARING) - QTY:1
BER0038 (BEARING) - QTY:1
BOL0058 (FLAT WASHER) - QTY:1
BOL0076 (LOCK NUT) - QTY:1
BOL0097 (COTTER PIN) - QTY:1 (*Part of Seal Kit #JMK0002)
BOL0110 (SLOTTED NUT) - QTY:1
BOL0111 (LOCK WASHER) - QTY:1
BOL0112 (FLAT WASHER) - QTY:1
BOL0113 (HEX BOLT) - QTY:1
IMP0026 (BRONZE IMPELLER) - QTY:1
KEY0017 (KEY) - QTY:1
MCSSET0009 (MECHANICAL SEAL SET) - QTY:1 (*Part of Seal Kit #JMK0002)
NIP0008 (DRAIN PLUG) - QTY:1
PORT001G (PLATE, PORT) - QTY:2
ORG0023 (O-RING, PORT PLATE) - QTY:2
ORG0024 (O-RING, BEARING HOUSING) - QTY:1
ORG0029 (O-RING) - QTY:1 (*Part of Seal Kit #JMK0002)
RET0020 (OIL SEAL) - QTY:1 (*Part of Seal Kit #JMK0002)
RIG0001 (DISTANCE RING) - QTY:1
SHA0084G (SHAFT) - QTY:1
SNP0016 (SNAP RING) - QTY:1
SNP0018 (SNAP RING) - QTY:1
SPC0003 (SPACER) - QTY:1 (*Part of Seal Kit #JMK0002)
SPC0005 (SPACER) - QTY:1
SPC0006 (SPACER) - QTY:1
SPC0007 (SHIM) - QTY:1
SPC0008 (SHIM) - QTY:1
JSK0124 Approx Total Lbs: 32 LBS / 14.55 kg
Services JMP Marine Caterpillar Replacement Engine Cooling Raw Water Pump & OEM / Genuine . . .
JMP Marine Engine Cooling Raw Water Pump: #JPR-CT3412
#JPR-CT3412 Replaces Caterpillar Pump P/N: 7C3613, 3N7790, OR7720
#JPR-CT3412 Replaces Gilkes Pump: M Series 250/700
#JPR-CT3412 good for Engine Models: 3408, 3408B, 3408C, 3412, 3412C, 3412D
Picture of Kit & Pump listed Above:
"Picture Coming Soon"
