Product Description
#JPR-ST7020 JMP Marine ST Series Seawater Strainer - 3" NPT Inlet / Outlet Ports
Includes:
- Complete Seawater Strainer #JPR-ST7020
QTY: 1
PRODUCT DESCRIPTION
SPECIFICATION | JPR-ST7020 |
PORT SIZE: | 3" (PIPE) - NPT |
TOP CASTING | Bronze |
BOTTOM CASTING | Bronze |
BASKET | Stainless |
BASKET REPLACEMENT P/N | FIL000502 (2mm) |
ANODE REPLACEMENT P/N | ZEN000101 |
SEAL | O-Ring |
SIZE (A X B X C, mm) | 260 x 445 x 275 |
CYLINDER (Dia X H, mm) | 210 x 250 |
WEIGHT (Approx.) | 36.0 lbs / 16.4 kgs |
PLEASE NOTE A,B,C SIZE STANDS FOR:
(A) Top Width / Dia = 260mm
(B) Height = 445mm
(C) Bottom Width / Dia = 275mm
PERFORMANCE TABLE - FLOW CHART
Bar | 500rpm | 1000rpm | 1800rpm | 2000rpm |
0 | 175 L/Min | 325 L/Min | 591 L/Min | 651 L/Min |
1 | 155 L/Min | 277 L/Min | 566 L/Min | 591 L/Min |
2 | 115 L/Min | 228 L/Min | 482 L/Min | 542 L/Min |
3 | 33 L/Min | 116 L/Min | 351 L/Min | 394 L/Min |
Max | 3.2 bar | 3.6 bar | 4.2 bar | -- |
PRODUCT FEATURES
- Robust Bronze Casting
- Robust Stainless with Chrome Plated Filter Baskets
- Easy Installation
- Easy Maintenance and Cleaning
- Protects Your Pumps and Engines
- Transparent and Strong Cylinder
- O-Rings Provide Better Sealing under High Pressure Applications
- Zinc Bar
- Wingnut
- Center Rods
- Air Cap
Image of Strainer
Please note that shipping cost calculations are based on packaged weight which can be higher than the actual product weight.
SHIPPING COST SAVINGS - BULK ORDERS:
Possible discounts on total shipping costs for multiple unit orders; please contact sales department at sales@bigblueoceanmarine.com or by phone at 1 (250) 713-1018 for bulk order shipping quotes. Bulk orders are usually based on an order of 3 units or more.
Warranty Information
Standard 1 Year Manufactures WarrantyProduct Videos
