Product Description
#JPR-S7632 JMP Marine Caterpillar Replacement Raw Water Engine Cooling Pump
Includes:
- JMP Caterpillar Replacement Engine Cooling Pump #JPR-S7632
QTY: 1
NOTE 1:
The Sherwood Impeller 27000, even though all the dimensions are the same, will not work in the JMP Marine pump since Sherwood makes their version with a threaded insert that is too thick and then bottoms out on the end of the shaft which prevents the complete impeller from fully seating in. If you use the Sherwood impeller you will have a clearance issue with the end cover and the impeller will heat up and melt. For the JMP Marine JPR-S Series pumps you must use impeller #7608-01K
Product Information:
| SPECIFICATION | JPR-S7632 |
| Uses JMP Impeller p/n |
7608-01 (Use on JPR-S7632). Search 7608-01K Note: JMP Impeller 7608-01 also used to replace Sherwood 27000 |
| Port Type | 1 3/4" Flange (1.75") |
| Pump Weight (approx) | 14.00 LBS (6.36 KG) |
| Replaces Genuine Caterpillar Pump p/n(s) | Caterpillar 4P7168, 113-1109, 152-8392, 167-4252, 170-6116, 353-7979 Note: 4P7168 for Engine Model 3116 / Sherwood P1710A/C/X 113-1109 for Engine Model 3126 / Sherwood P1726X (replaced by P1732C) 152-8392 for Engine Model 3126 / Sherwood P1726X (replaced by P1732C) 167-4252 for Engine Model(s) 3126B, C7 / Sherwood P1726X (replaced by P1732C) 170-6116 for Engine Model(s) 3126, 3126B, C7, C9 / Sherwood P1726X (replaced by P1732C) |
| Genuine Caterpillar Impeller p/n |
CAT Impeller 7E0321 (On Engine Models: 3116, 3126, 3126B, 3208, C7, C9) Please Note: CAT 7E0321 = JMP 7600-01 (replacement Impeller to use) JMP 7608-01 (Replacement Impeller to use) = Sherwood 27000 |
| For Engine Model(s): |
3116, 3126, 3126B, C7, C9 |
| Replaces Sherwood Pump p/n(s): |
P1710, P1710-01, P1710-02, P1710-04, P1710A, P1710C, P1710X, P1726, P1726X, P1732-01, P1732-02, P1732A, P1732C, P1732X Note: P1726X replaced by P1732C |
| Sherwood Pump Impeller P/N: | 17000K (note: JMP 7600-01K replaces Sherwood 17000K) |
| Parts Internally Compatible to Genuine | NO (Changes Made to Impeller, Wear Plate, Cam, Mechanical Seal, and Shaft for Better Quality & Performance) |
| Major Service Kit (All Internal Parts) *Sold Separately |
JSK0072 (For JPR-S7632 Pump) |
| Minor Service Kit *Sold Separately |
JSM0002 (For JPR-S7632 Pump) |
Features:
- 100% Plug & Play Replacement
- Universal Type
- Heavy Duty Marine Grade Casting
- Marine Grade Shaft (3X Series Non-Magnetic)
- O-Ring End Cover Packing
- Spline Drive Shaft (Not Key Drive)
- High Performance Impeller
- High Volume Flow Capacity
- Fast Flow Velocity
- CAT Impeller 7E0321 = Use JMP 7600-01
- JMP Impeller 7608-01 = Also used to Replace Sherwood 27000
JMP MARINE . . ."THE ONLY ONE"
