Product Description
#JPR-CT3054 JMP Marine Caterpillar & Perkins Replacement Engine Cooling Raw Water / Seawater Pump (Complete pump Assembly)
Includes:
- JMP Caterpillar & Perkins Replacement Engine Cooling Raw Water Pump #JPR-CT3054
QTY: 1 - Includes Drive Gear
Product Information:
| SPECIFICATION | JPR-CT3054 |
| Uses JMP Marine Impeller p/n |
7400-01 (search 7400-01K) |
| Pump Weight (approx) | 8.50 LBS (3.90 KG) |
| Replaces Genuine Caterpillar Seawater Pump p/n(s) | Caterpillar 4255411, 425-5411 |
| Replaces Jabsco Pump p/n |
29630-1301S |
| Replaces Perkins Pump p/n | W100000 |
| For Caterpillar Engine Model(s): |
3054, 3056 |
| For Perkins Engine Model | M92B |
| Drive Gear - Number of Teeth | 28 Teeth on this drive gear |
| End Cover Screw Qty | 6 |
| JMP Internal Parts Compatible to Genuine? | YES & NO (SEE NOTE "A") - Major & Minor Kits |
| NOTE "A" Only applicalbe if servicing or rebuilding other pump brands using JMP Marine Part Kits |
This does not apply when major and minor kits are being used to service a JMP Marine brand pump #JPR-CT3054; this note only applies when internally servicing an OEM Genuine pump brand. Why was Mechanical Seal Changed? |
| Major Service Kit (All Internal Parts) *Sold Separately |
JSK0142 |
| Minor Service Kit *Sold Separately |
JSM0142 |
Features:
- 100% Compatible Plug & Play Replacement (Pump & Parts, except M-Seal . . See Note "A" in Product Information)
- Long Life Mechanical Seal
- Heavy Duty Marine Grade Casting
- Heavy Duty Bronze Cam Liner
- Marine Grade Shaft (3X Series Non-Magnetic)
- High Performance Impeller
- High Volume Flow Capacity
- Fast Flow Velocity
JMP MARINE . . ."THE ONLY ONE"
